BBC TVC Main Block Studios
BBC TVC Main Block Studios
FORMATION
SIGNIFICANT EVENTS
Addition Of TC9
New material to be added here.
BUILDING LAYOUT
Disclaimer
Whilst some care has been taken to check externally linked websites no responsibility is offered nor implied for the suitability, legality or reliability of content therein.
Main Block Studios were the central significant part of the centre of Television Centre. Apart from it being very convenient to have the control rooms for all these studios located in one place the fact that they were laid out in a circle was a technical necessity in those days. For the equipment in each studio to work each one needed a precisely matched set of seven timing pulses distributed from a central point. Having produced beautiful vision and sound they needed to be recorded or distributed to the transmitters. If each of the studios received precisely co-timed pulses and were equidistant from those two collection points then it would be possible to cut and mix between studio outputs. A concept known a synchronous play in. As television was very often live in those days this was a significant advantage. As a contrast Independent TV companies were often geographically disparate and they did not have the luxury of synchronous play in and so when changing from one programme to the next they would fade to black, perform a non-sync cut where the scanning of the television display at home would roll for a second or so, and then they would fade the next programme up. TV Centre’s fundamental shape negated the need for this.
Convertion Of The Music Studio ‘TMS’ To TC0
New material to be added here.
Handover Of TC7 To News & Current Affairs
New material to be added here.
Conversion Of TC2 Make-Up Room To Electronic Graphics Production Area
New material to be added here.
Convertion Of TC2 From Scenery Store To Studio
New material to be added here.
Layout Of Main Block
New material to be added here.
Layout Of Studios
The floor plans of individual studios are here:
Studio0 -Not currently available
Studio5 -Not currently available
TC7 -current not available
TC9 -current not available
TC10 -current not available
